V Type Hydraulic Piston Pump Eaton Vickers Pvxs250 Hydraulic Open Circuit Pump

Supply Ability : 500pieces/Year

Payment Terms : L/C, T/T, D/P, Western Union, Paypal, Money Gram

Brand Name : Eaton Vickers

Model Number : Pvxs250

Certification : GS, RoHS, CE, ISO9001

Place of Origin : China

MOQ : 1 pcs

Price : discussible

Delivery Time : 5days

Packaging Details : Wooden box

Model NO. : PVXS-250-M-R-LR-0024-018 Hydraulic-Piston-Pump

After-sales Service : Free Warranty

Warranty : Free Warranty

Structure : Axial Plunger Pump

Cylinder Number : Single Cylinder

Drive Mode : Mechanically Driven Pump

Pump Shaft Position : Horizontal

Type : V Type

Power : Electric

Straight Shaft Swashplate Piston Type : Pressureoil

Radial Plunger Pump Type : Valve with Flow

Trademark : MKS

Transport Package : Wooden Box

Specification : cast iron

Origin : China

HS Code : 8413503190

Port : Foshan, China

Contact Now

Axial Plunger Pump Structure V Type Eaton Vickers Pvxs250 Hydraulic Open Circuit Pumps

Basic Info.

Model NO.
PVXS-250-M-R-LR-0024-018 Hydraulic-Piston-Pump
After-sales Service
Free Warranty
Warranty
Free Warranty
Structure
Axial Plunger Pump
Cylinder Number
Single Cylinder
Drive Mode
Mechanically Driven Pump
Pump Shaft Position
Horizontal
Type
V Type
Power
Electric
Straight Shaft Swashplate Piston Type
Pressureoil
Radial Plunger Pump Type
Valve with Flow
Trademark
MKS
Transport Package
Wooden Box
Specification
cast iron
Origin
China
HS Code
8413503190

Product Description


Introduction
• Axial piston pumps with swashplate design for reliable operation and long life.
• Pressure up to 420 bar. Rated speed up to 1800 min-1. Higher speeds possible.
• Oversize shafts and bearings.
• Rotating and pressure loaded parts are pressure balanced.
• Integrated pilot pump, filter and pressure relief valves available.
• "Building block" design gives these pumps a wide range of application.
• Fast response times.
MODEL 66 90 130 180 250
Design Swashplate - Axial piston pump
Type of mounting Flange or foot-mounted. tandem is foot mounted only
Pipe connection SAE/Flange B psi 1 1/2" = 3000 2" = 3000 2 1/2" = 3000 2 1/2" = 3000 3 1/2" = 500
A 1" = 6000 1" = 6000 1" = 6000 1 1/4" = 6000 1 1/4" = 6000
Direction of rotation Clockwise when viewing shaft end of pump Counterclockwise available on request
Speed range nmin min-1 150
nmax 1800
Installation position Optional, see mounting information
Ambient temperature range min °C -20
max 50
Weight m kg 55 75 106 114 212
Mass of inertia J kg m2 0.016 0.016 0.045 0.045 0.146
HYDRAULIC CHARACTERISTICS
Nominal pressure (100% duty cycle) pN bar 350
Input pressure p1min p1max bar bar 0.85 abs 50
Maximum pressure to DIN 24312 p2max bar 420
Hydraulic fluid Hydraulic oil to DIN 51524 part 2. Refer to section Application Data-Fluid Recommendations
Hydraulic fluid temperature range min max °C -25 (on start up) 90
Viscosity range for continuous operation min cSt 10
max cSt 75
Maximum permissible start viscosity max cSt 1000
Filtering ISO 4406 18/15/13
Maximum geometric displacement n= 1500 min-1
n= 1800 min-1		 Vg cm3 66 90 130 180 250
Maximum geom. n= 1500 min-1 Qg L/min 99 135 195 270 375
pump flow n= 1800 min-1 118 162 234 324 450
Case pressure pv max bar max. 0,5 bar over p1. pmax = 4 bar abs.
DRIVE
Maximum driving torque - single unit
(p2 max., -r= 100%)		 M1 Single Nm 440 600 868 1202 1671
Maximum power consumption - single unit P1 Single
(p2 max., -r= 100%; n= 1800 min-1)		 kW 69 94 136 189 265
Maximum driving torque limited to splined shaft only - comb. unit M1 Comb. Nm 2x440 2x600 2x868 2x1202 2x1671
V Type Hydraulic Piston Pump Eaton Vickers Pvxs250 Hydraulic Open Circuit PumpV Type Hydraulic Piston Pump Eaton Vickers Pvxs250 Hydraulic Open Circuit Pump
